40 Series Rear Bumper

Regular price $ 1,695.00 USD
Regular price Sale price $ 1,695.00 USD
Sale Sold out


4X4LABS expedition bumpers offer the best protection, highest clearance and have more available options than anything else on the market by far. We have been building this bumper for over 15 years. Our design has evolved into a simple, modular and customizable system. Every part carefully engineered delivers performance, function and durability. The design is simple and beautiful following body lines and curves of your Land Cruiser.

  • High clearance bumper profile with built in tail light protection and two recovery points
  • All tail light designs available - early, mid and late stock tail lights or custom upon request
  • Swing outs that are included in the price accept a variety of attachments (not included) and can be switched out or removed
  • Heavy duty spindles and latch assure a rattle free bumper forever

Every detail of the bumper systems have been engineered and designed for use in demanding off road environments. The swing arms will accept a variety of different bolt-on attachments that can be ordered separately or added later.

Main Shell formed 1/4” cold rolled steel, angular shell design creates the high clearance 4x4labs bumper profile.

All tail light options are available - Early 4" roundies, mid-year 4-1/2" roundies or the rectangular multi function lights found on the later years. We can leave that area blank for use with custom LED's or light assemblies of your choice. All tail light areas are guarded by a 3/8" formed skid plate around the light.

Mounting bolts for each year line up with existing frame holes eliminating the need to drill new holes in your frame. Towing bolt holes from the factory are retained as part of the mounting. Two recovery points are included and a 2" standard towing receiver can also be ordered as an option.


Our clever swing out solution is the key to the functionality of this system. Our own heavy duty spindles welded through the main shell of the bumper for optimum strength. Sleeved swing arms give you the option of which attachments to carry or leave at home.



BUILT BUMPERS ship via semi-truck LTL freight to a commercial address and must have a forklift and/or a loading dock. Additional shipping fees of at least $150 will apply to residential deliveries.
